Adaptateur secteur Mysa C-Wire

Fournit une alimentation 24 V fiable à votre thermostat Mysa lorsqu'aucun fil C n'est disponible. S'installe au four, à la chaudière, à l'équipement de zone ou au traitement d'air.

$30.00

Modèle

Aidez-moi à choisir

Options supplémentaires

assignment_return Essai de 30 jours sans risque avec retours gratuits
delivery_truck_speed Livraison gratuite pour les commandes de plus de 100 $
shield Garantie de 5 ans, la meilleure de sa catégorie
timer Livraison rapide en 3 jours ou moins

Liens utiles

Détails des prix
  • Adaptateur secteur Mysa C-Wire × 1 $30.00
$30.00

Beaucoup de maisons n'ont pas de fil commun (fil C) au thermostat, et tirer un nouveau fil dans les murs est une corvée. L'adaptateur d'alimentation pour fil C de Mysa fournit une alimentation continue de 24 V c.a. à votre thermostat intelligent Mysa en réutilisant votre câblage existant. Conçu pour gérer les installations les plus complexes, y compris les systèmes à deux fils en chauffage seul ou en climatisation seule, où vous n'avez que les bornes R et W (ou R et Y) au thermostat.

Check Fournaises au gaz et au mazout
Check Climatiseurs et thermopompes
Check Chaudières à eau chaude avec systèmes hydroniques
Check Robinets de zone 24 V et cartes de commande de robinets de zone
Check Configurations à relais 24 V
Check Configurations millivolt/contact sec (nombreux foyers)

Compatible avec le thermostat intelligent Mysa seulement

L'installation se fait à votre fournaise, chaudière, appareil de traitement d'air ou panneau de vannes de zone. Notre guide en ligne crée des instructions personnalisées selon votre câblage exact, avec 11 schémas différents couvrant la plupart des configurations.

Installation standard (fournaise/appareil de traitement d'air) :

  1. Coupez l'alimentation au disjoncteur
  2. Repérez la carte de commande
  3. Étiquetez les fils du thermostat existant à l'aide des autocollants fournis
  4. Photographiez votre câblage pour référence
  5. Réacheminez les fils dans l'adaptateur en suivant votre guide personnalisé
  6. Fixez l'adaptateur à l'aide du coussinet adhésif fourni
  7. Rétablissez l'alimentation et vérifiez que le thermostat s'allume

Systèmes à chaudière et à vannes de zone : Pour les systèmes hydroniques à vannes de zone, installez l'adaptateur à la vanne de zone — et non à l'aquastat de la chaudière. Les configurations à plusieurs zones nécessitent un adaptateur par thermostat.

Option de transformateur externe : Les chaudières plus anciennes ou les systèmes sans alimentation 24 V suffisante peuvent utiliser la borne Rext avec un transformateur standard de 24 V c.a. (vendu séparément, environ 15 à 20 $ en quincaillerie). Un seul transformateur alimente jusqu'à trois combinaisons Mysa + adaptateur.

Modèle : MYSA CWA V2-0

Tension d'entrée : 20–30 V c.a.

Intensité nominale : 8 A (2 A max sur W/Y/OB)

Température de fonctionnement : 0 °C à 50 °C (32 °F à 122 °F)

Type de relais : contact sec isolé

Alimentation externe : borne Rext pour transformateur de 24 V c.a.

Longueur du faisceau de fils : ~12 po (30 cm)

Indice de protection : IPX0

Dimensions : [à venir]

Couleur : blanc

Notre politique de retour est simple. Les factures d'électricité élevées ne reviendront pas. Toutefois, si vous devez retourner votre Mysa, c'est tout aussi simple : expédition et retours gratuits, avec un soutien d'experts à chaque étape.

Vous exigez la durabilité. Après un million d'appareils vendus et des années de perfectionnement technique, nous garantissons la fiabilité des nôtres. C'est pourquoi chaque Mysa inclut une garantie de 5 ans—plus du double de la norme de l'industrie.

Que contient la boîte

Caractéristiques

Bolt Alimentation 24 V fiable
Build Aucun nouveau câblage
House Compatible avec deux fils
Quick_Reference Guide d'installation personnalisé
Package_2 Quincaillerie incluse
Eco Moins de déchets électroniques

Controlez de n'importe ou

"Les 4 meilleurs thermostats intelligents de 2025"

~ Wirecutter / New York Times

"Fonctionne comme prévu… j’ai enfin pu me débarrasser du vieux thermostat des années 1980 qui ne faisait que chauffer au maximum."

~ Derek F.

"Fait une bien meilleure job que les autres thermostats intelligents que j’ai utilisés, et l’application te donne toute l’info dont t’as besoin pour tirer le maximum de ton budget de chauffage."

~ Ian V.

''Le guide étape par étape m’a vraiment aidé et a rendu les choses plus faciles pour un installateur débutant comme moi.''

~ Chris L.

'L’équipe d’assistance Mysa est formidable ; Leigh m’a aidé avec l’installation et a rendu l’ensemble du processus très fluide.''

~ Anmol A.

'Fiable, élégant et nettement amélioré.''

~ La Presse

Questions fréquentes avant l'achat.

Puis-je l'installer moi-même ?

Oui. L'installation exige une aisance de base avec le câblage électrique au niveau de votre fournaise ou de votre chaudière. Notre guide en ligne génère des instructions adaptées à votre configuration, avec 11 schémas de câblage. Si vous n'êtes pas à l'aise avec le câblage CVC, faites appel à un technicien qualifié (environ 75 à 150 $).

Ai-je besoin de l'adaptateur d'alimentation C-Wire ?

Plus de 55 % des vérifications de compatibilité nécessitent cet adaptateur. Les maisons construites avant 2000 et les systèmes hydroniques sont les cas les plus fréquents.

Qu'est-ce qui est inclus ?

L'adaptateur, un connecteur de fil pour les configurations avec transformateur externe, un tampon adhésif de montage, des autocollants d'identification de fils et le guide d'installation.
